Skwing SE6000 Long Range Fixed Wing Drone 6000mm Wingspan
Skwing SE6000 Long Range Fixed Wing Drone 6000mm Wingspan
SKYWING SE6000 UAV, Experience optimal reliability and durability in challenging environments with the carbon fiber 6000mm UAV Fixed Wing Drones Platform. Made with high-quality carbon fiber material, this platform features a strengthened internal rib structure and easily transportable two-piece booms for a longer lifespan. One noteworthy aspect of the SE6000 model is its Disc Brake System. This cutting-edge braking mechanism allows for safe and effective landings by equipping the UAV with the capability to brake during landing, minimizing the potential for incidents and enhancing overall safety. When seeking to swiftly and effectively gather top-notch aerial data, the SE6000 UAV is a superb choice. Whether one's field is research, farming, or delivery, this drone provides the necessary ca
Procurement note: Final configuration, selected variant, payload compatibility, export/compliance requirements, warranty, lead time, and packing details should be confirmed before purchase.
Request a Quote Browse Catalog
SKYWING SE6000 UAV, Experience optimal reliability and durability in challenging environments with the carbon fiber 6000mm UAV Fixed Wing Drones Platform. Made with high-quality carbon fiber material, this platform features a strengthened internal rib structure and easily transportable two-piece booms for a longer lifespan.
One noteworthy aspect of the SE6000 model is its Disc Brake System. This cutting-edge braking mechanism allows for safe and effective landings by equipping the UAV with the capability to brake during landing, minimizing the potential for incidents and enhancing overall safety.
When seeking to swiftly and effectively gather top-notch aerial data, the SE6000 UAV is a superb choice. Whether one's field is research, farming, or delivery, this drone provides the necessary capabilities and adaptability to fulfill all requirements.
SKYWING Carbon fiber 6000mm UAV Fixed Wing Drone diagram showing dimensions.
SKYWING Carbon fiber 6000mm UAV Fixed Wing Drone hatch opening mechanism
SKYWING Carbon fiber 6000mm UAV Fixed Wing Drone Prototype Display in The Production Workshop
SKYWING carbon fiber fixed wing drone with open payload bay (1000x345x350mm) being loaded on grassy field.
| SKYWING Carbon fiber 6000mm UAV Fixed Wing | |||
| Name | Specification | KIT | PNP |
| Flying platform | Outer wing | 2 | 2 |
| Center wing | 1 | 1 | |
| Main body | 1 | 1 | |
| undercarriage | 1 | 1 | |
| Plain tail | 1 | 1 | |
| Stern stay | 2 | 2 | |
| Front stay | 2 | 2 | |
| hatchcover | 1 | 1 | |
| Fuel tank | 1 | 1 | |
| Engine hood | 1 | 1 | |
| Power system | DLE170 Engine | 1 | |
| Servo | 9 | ||
| 32*12 Propeller | 1 | ||
| Wire bale | 1 | ||
| Installation service | 1 | ||
| PARAMETER | wingspan | 6000mm |
| Length | 3670mm | |
| Maximum fuselage width | 375mm | |
| Wing area | 261.5 dm2 | |
| Equipment bay dimensions | 920mmx340mmx350mm | |
| Tank volume | 30L | |
| Weight and Payload | Empty weight | 33.64kg |
| Maximum take-off weight | 90kg | |
| payload | 30kg | |
| Flight Characteristics | Top speed | 140km/hr |
| Cruising speed | 115km/hr | |
| Stall speed | 55km/hr | |
| Take-off distance | 60M | |
| Landing distance | 85M | |
| Maximum flight time | >8H | |
| Packaging Information | Wing section | 190*50*95cm |
| Fuselage section | 190*50*48cm |
